Join Dipstick® Next Week at World of Concrete 2015
WOC 2015 is set for February 3rd through the 6th in Las Vegas. Come by to see us in Booth C4102 – almost right at the “front door” of the Central Hall!
We also invite you to join us for the 2014 Golden Trowel® Awards. We have new world records to recognize – and our first Golden Trowel award winner from Europe! The ceremony is on Thursday, the 5th, between 12:00 and 1:00 PM in Room N119 of the Las Vegas Convention Center.
The Dipstick® Profiler is:
by far the most accurate and most specified concrete floor and pavement profiler in the world;
by far the least expensive profiler to buy and own – because it never needs recalibration – which saves many thousands of dollars over the life of the instrument;
the only profiler that instantly produces reports, graphs, line surveys and 3D surface studies;
the only profiler that measures Fmin (for defined traffic floors) at no extra charge;
the Fastest Way to the Right Answer™ – just as fast as any other floor profiler when they are used according to their instructions; and
the profiler that measures the most flatness/levelness indices, using the most extensive standard software package in the industry.
The best performance and the lowest cost are two reasons that Dipstick is used and specified in 63 countries by clients including the world’s biggest company and retailer, the World Bank, the World Road Association. Dipstick was selected for the construction of the world’s tallest building and to measure the flattest and most level superflat slab ever constructed.
It’s been almost 40 years since The Face® Companies started developing what became modern concrete floor flatness/levelness technology. After building the first reliable floor flatness/levelness measuring device (the Face Floor Profileograph) and developing the placement and finishing techniques that resulted in what Face called “Superflat floors,” a team of Face Companies engineers and flat floor consultants invented the Dipstick and introduced it at the 1982 World of Concrete. Ever since, the Dipstick has been the gold standard for the measurement of concrete floor and pavement profiles.
Dipstick measures far more flatness/levelness indices than any other profiler:
Face Floor Profile Numbers (“F-Numbers” – FF and FL – ASTM E1155);
Fmin (the only profiler that measures Fmin at no extra charge);
TR-34 Free Movement (FM); TR-34 Defined Movement (DM);
Gap under Sliding Unleveled Straightedge and Gap under Rolling Straightedge;
Joint Profiles; Joint Movement under Load; Thickness of Toppings, Fills and Coatings; Construction Forms; International Roughness Index (IRI); ASTM E1926-08; AASHTO R 41; Rut Depth; Slab Upheaval, etc.; and
it’s the only profiler that instantly produces reports, graphs, line surveys and 3D surface studies.
Watch this Video to Learn About the Dipstick Floor Profiler (2:27)
Watch More Videos Below and in The Flat Floor Library ™
Para ver el video en Español haga click aqu¡ – Click here to watch this video in Spanish
El manual para el Dipstick está disponible en español – The Dipstick Manual is available in Spanish
点击这里观看此视频在中国 – Click here to watch this video in Chinese
该手册对这款产品发表在中国语文 – The Dipstick Manual is available in Chinese
Why is the Dipstick the Most Specified Flatness/Levelness Measuring Instrument in the World?
By Far the Best Accuracy
Produces a Better Profile than a Rod & Level
Testing labs, building owners, developers, contractors, universities, research institutions and government agencies on six continents choose the Dipstick because it produces the most accurate and repeatable flatness/levelness data – period. Dipstick readings are guaranteed to be accurate to 0.0125 mm – less than 0.0005″ (that’s 5/10,000ths of an inch!). Based on the thorough testing of every unit we manufacture, Dipsticks are typically accurate to 0.005 mm (0.0002″). No other instrument comes close. Why? Constant design and electronic improvements in an ongoing effort to improve what is already unparalleled performance. Although it looks the same, the Dipstick of today doesn’t include a single component that was part of the Dipstick of 20 years ago.
In fact, the Dipstick is so accurate that it’s routinely used to calibrate other measuring instruments!
Watch this Demonstration of the Precision, Accuracy and Repeatability of the Dipstick Profiler (1:11)
Data & Graphs Now… On-site!
Only the Dipstick instantly calculates F#s and instantly produces graphs on-site.
Truly Economical… the Fastest Way to the Right Answer™
The Dipstick operates at up to 1,200 readings per hour … the fastest way to the right answer… the true measure of economical operation.
Measure, analyze and report combined F-Numbers for a 10,000 sq.ft. (1,000 square meter) slab in 30 minutes or less! Measure American Concrete Institute / ASTM FF & FL (Random Traffic) and Fmin (Defined Traffic). With the rolling instruments on the market, you can’t measure Fmin at all. With another device, you have to pay extra software rental fees to measure Fmin. Dipstick calculates Fmin on-site… with at least four to ten times the accuracy of its competitors… for free.
Lowest Total Cost of Ownership
Because we sell so many instruments, the purchase price of the Dipstick is less than some other profilers, even though Dipsticks are the highest quality instrument – even coming with their own HP color computer! But, when you figure in the costs of maintaining your profiler once you’ve bought it, over its lifetime, a Dipstick will cost 40% to 75% less than other profilers. Dipsticks should continue to produce accurate data for 15 years or more.
Never Needs Recalibration – Saves $7,500 to $30,000 over the Life of the Instrument
With Dipstick, there’s No Expensive and Inconvenient Annual Recalibration.
With other profilers, you have to pay $500 to $1,000 or more every year in calibration fees and the shipping costs back and forth. That means you’ll pay $7,500 to $15,000 or more in extra costs over the life of those instruments.
For customers outside North America, those extra costs could easily double to $15,000 or $30,000 in recalibration fees, high international shipping costs (in both directions) and the costs of clearing customs again and again.
Moreover, with those other profilers, while you’re paying the extra fees and the round trip shipping costs, you will also lose the use of the instrument for weeks or months at a time while it’s being calibrated and shipped back and forth.
Watch the Dipstick Precision, Accuracy and Repeatability video above to see the performance of six different Dipsticks – up to nine years old – that had never been recalibrated.
You can easily check the calibration of your Dipstick yourself. This process is described in the Dipstick Operator’s Manual.
The Best Software
The Dipstick has by far the most complete and frequently updated flatness/levelness software packages you can buy:
Instant On-Site Graphs
At Run Level – At Section or Pour Level – At Surface or Project Level
Instant ASCII Files
for Export to Other Software
Instant Straightedge Analyses
Graphic & Tabular Reports – Rolling or Sliding Straightedge
Non-Destructive Measurement of the Thickness of Toppings, Fills & Coatings
No Coring Required
Here’s How to Measure the Thickness of Toppings, Fills, Overlays & Coatings (1:42)
Includes 1155 Helper™ Software
Includes Windows® Analysis Software
Free Software Upgrades
Free software upgrades as long as you own your Dipstick
The only true Windows®-compatible software in the industry
Cut and paste Dipstick reports
Print from any Windows® computer to any printer
Dipsticks feature instant downloading
Both English & Metric Collection & Analysis
Windows® Software Included
More Features You Won’t Find with Other Profilers:
Can Be Switched in Minutes from 12-inch to 300 mm or 250 mm Measuring Increments
Step Over Joints, Sawcuts, Discontinuities & Rebar – Something NO Rolling Device Can Achieve
Instant Spot Elevations
Easy Form Measurement – Another Thing NO Rolling Device Can Achieve
Floor Levelness Is Largely Determined by Form Work
Measure Joint Profiles in Accordance with ASTM E1155
Measure Joint Movement under Load to Help to Determine if Joints Will Crack or Spall
Produce 3D Topographic Maps / Analyses of Floor Surfaces
On-Site Earthquake & Other Structural Damage Assessment & Reports
The Dipstick Is Delivered as a Complete Kit with All Accessories
Each Dipstick kit is shipped in its own customized ZERO® aluminum carrying case, which is sized to fit into overhead storage compartments on most commercial aircraft.
Free Telephone Tech Support for the Life of the Instrument
Our expert technicians are available by telephone each business day to answer your questions about F-Number measurement, floor flatness and levelness, the many applications of Dipstick Profilers and to provide any other technical help that you may need. The great majority of callers on our technical assistance lines are helped immediately. With other companies, you might wait days for technical help.
The Fastest Delivery and Best Service in the Industry
We have more technical and service personnel than all of our competitors combined. With the Dipstick, you won’t have to wait weeks for your new, upgraded or repaired instrument.
So, when it comes to flatness/levelness measurement, it’s really simple…
Dip It… or Skip It! ™
Why Don’t The Face Companies Sell a Rolling Floor Profiler?
We get this question from time to time. The truth is the first rolling device ever made to measure concrete floor profiles was developed by The Face Companies in the late 1980s and early 90s. We wanted it to be a “quick check” profiler for contractors to estimate their FF numbers. But our rolling device never produced repeatable data. Each time we measured the same line, we got different F-Numbers. The FFs would vary by 10% or so. The FLs would change by as much as 25% each time we measured the same line. We decided not to sell the product because the quality of the data it produced didn’t meet our standards.
The rolling profilers on the market suffer from the same problems we had 20 years ago, as a third-party comparison of Dipstick and the leading rolling profiler revealed. For instance, rolling devices have wheel slippage and they jostle as they are manually pulled… or mechanically driven… across the floor. These problems throw off the profiler’s reading of both the surface conditions and the distance it travels. That hurts the F-Number calculation. They also have problems when they roll over even tiny debris on the floor such as grains of sand… which act like micro speed bumps for the profiler’s hard wheels. That introduces more errors in the profile measurement. It doesn’t take many errors… even tiny mistakes… to make the F-Numbers reported unreliable… particularly the FLs.
Others have recognized this reality. One rolling profiler doesn’t even try to measure FL. It reports only an FF number.
And there are other problems: Rolling devices can’t deal with real-world problems like joints, sawcuts, rebar and other surface discontinuities. Dipstick walks right over them.
In addition, rolling devices can’t measure forms… and better forms are the key to better FLs. Dipstick is perfect for this, too.
Some people think rolling devices are “faster.” But, if they’re used so as to minimize the effect of the errors in data collection, they’re no faster than the Dipstick. But really, what is the advantage of a “faster” profiler that produces different data each time it measures the same line? What good are data that you can’t count on?
We want our products to maintain the reputation of Dipstick. Our profiler is so accurate and reliable that it’s the only device used by governments and industry bodies around the world to calibrate other profiling devices. And that’s been the case for more than 15 years. Experts in 63 countries know that Dipstick produces reliable, repeatable data. And that’s why we say… Dipstick is the fastest way to the right answer!™
Have any Model 2000 or 2200 Dipstick?
Now’s the time to Upgrade to a Model 2272.
Call 1-800-F-NUMBER (that’s 1-800-368-6237) in the USA & Canada
Call 757-624-2121 Worldwide
or email Dipstick@FaceCo.com for details.
